Euro Energy offers highly robust and protective composite barrier systems. By fusing high-performance geomembranes with protective woven or non-woven geotextile backings, our Composite Geomembrane series delivers outstanding puncture resistance, hydraulic separation, and load-bearing reinforcement for critical containment designs.
Tinhy composite geomembrane is a geosynthetic material made of geotextile (nonwoven fabric, woven fabric) and polymer material (HDPE/LLDPE/EVA), which is calendered and hot melted. It combines the benefits of both geomembrane and geotextile, which removes the needs for protection layer, it has the properties of high tensile strength, tear resistance, high bursting strength, root penetration resistance, anti–aging, etc. It has the benefits of fast stress dispersion, small displacement, fast construction and low cost.
ASTM, GB/T, CJ/T
Fabric material: PET, PP Color: black, white
Width: 2m~7m, Weight: 200–3500g/m²
Canal and Pond Linings, Road and Railway Construction, Mining Applications, Water Containment and Treatment, Erosion Control, Aquaculture Ponds, Agricultural Applications, Tunnel and Underground Construction.
Our composite geomembranes are customizable into diverse structural configurations to provide the precise level of separation, tensile strength, and cushioning needed for your specific geotechnical parameters:
Consists of one geotextile layer bonded to a single geomembrane sheet. Highly effective for preventing sliding on mild slopes and protecting the lining core during baseline soil work.
Features a protective geotextile sandwich on both sides of the inner geomembrane core. Completely eliminates the need for thick soil protection backfill layers.
An ultra-duty, multi-layered layout utilizing three geotextile separators and two geomembrane cores. Engineered for deep waste cells, tailing lakes, and heavy hydraulic channels.
